- Features
- Valve shall be double blocking with union ends
- Valves shall be full port
- Valves shall allow for bidirectional flow
- Valve body shall be single end entry with a threaded carrier
- The threaded carrier shall be adjustable with the valve installed
- Valve body shall have an expansion and contraction compensating groove on the molded end
- The valve body, union nuts, and carrier shall have deep square style threads for increased strength
- The ball and stem shall be machined smooth to minimize wear on valve seats and seals
- Valve seats shall have o-ring backing cushions to compensate for wear and prevent seizure of the ball
- The stem design shall feature double o-ring seals as well as a safety shear point above the o-rings
- Valves shall have integrally molded mounting features for actuation
- Valves shall have integrally molded support bracketing for anchoring
- Standards/Approvals: ANSI B1.20.1, NSF 61 Certified
- Applications: For acid products handling for refineries, metal works, pharmaceutical, swimming pools and water and wastewater treatment applications
